Claude Code Structured Output Mode in 2026: Forcing JSON Responses From Subagents and Validating Them With Zod

Claude Code Structured Output Mode in 2026: Forcing JSON Responses From Subagents and Validating Them With Zod

Disclosure: jsmanifest has a financial interest in NoCensor AI and may earn from signups through links in this article.

Pass outputFormat to subagent sessions, validate structured output with Zod schemas before results reach the lead agent, and compose multi-agent workflows with type-safe JSON pipelines in Claude Code SDK v0.3.301+.

Correction (2026-11-02): the original version of this post invented a startSubagent() function and a hookSpecificOutput.structuredOutput/behavior: "cancel"/"allow" contract on the SubagentStop hook; structured output is a query() option, and the SDK validates and retries it internally, so your own code reads message.structured_output from the result message instead of a hook.

Claude Code Structured Output Mode in 2026: Forcing JSON Responses From Subagents and Validating Them With Zod

Subagents in Claude Code return unstructured text by default. When a lead agent spawns five parallel subagents to extract metadata from API endpoints, the lead receives five prose summaries. Parsing those summaries for the actual data means regex patterns, fallback heuristics, and silent failures when a subagent changes its response format mid-conversation.

%% alt: Problem flow showing subagent returning unstructured text that the lead must parse
flowchart LR
    Lead("Lead agent spawns subagent")
    Sub("Subagent completes task")
    Text("Returns prose summary")
    Parse("Lead parses text with regex")
    Fail("Parsing fails silently")

    Lead --> Sub
    Sub --> Text
    Text --> Parse
    Parse --> Fail

    style Fail stroke:#fbbf24,fill:#3a2f0b,color:#fef3c7
Problem flow showing subagent returning unstructured text that the lead must parse

Structured output mode forces subagents to return validated JSON that matches a schema you define. The lead receives the exact shape it expects, and Zod validates every field before the result reaches the lead's context. No parsing, no silent failures.

%% alt: Solution flow showing subagent returning validated JSON schema
flowchart LR
    Lead("Lead agent spawns subagent")
    Sub("Subagent with outputFormat")
    Schema("Returns validated JSON")
    Type("Lead receives typed object")
    Safe("Type-safe downstream use")

    Lead --> Sub
    Sub --> Schema
    Schema --> Type
    Type --> Safe

    style Safe stroke:#34d399,fill:#0b3b2e,color:#d1fae5
Solution flow showing subagent returning validated JSON schema

This post shows how to pass outputFormat to a query() session you run as a worker, validate structured output with Zod as soon as it lands on the result message, and compose JSON schemas for multi-agent workflows that demand reliability. Examples run on Claude Code SDK v0.3.301 with Claude Fable 5.1 (claude-fable-5-1), which dropped support for tool_choice types any and tool in the September 1, 2026 release. The structured output and strict tool use patterns here replace the removed tool-choice guarantees.

Claude Code structured output validation workflow

Key Takeaways

  • Structured output mode forces subagents to return validated JSON matching a schema, eliminating regex parsing and silent format drift.
  • Pass outputFormat: { type: "json_schema", schema: zodSchema } to query() to constrain an agent session's final result.
  • Zod schemas generate JSON Schema with .toJSONSchema(schema, { target: "draft-7" }) and provide TypeScript types through inference.
  • The SDK wraps the result in a synthetic StructuredOutput tool call, validates it against your schema, and retries automatically, so your own code only ever sees validated JSON on message.structured_output or a terminal retry error.
  • On validation failure, the SDK re-prompts the agent with the mismatch up to the retry limit; only error_max_structured_output_retries reaches your result-handling code if every attempt fails.

Understanding Claude Code Structured Output Mode: The Synthetic Tool Pattern

Structured output mode wraps the subagent's final response in a synthetic tool call. The SDK generates a tool definition from the schema you provide, instructs the model to call that tool with the result, validates the call against the schema, and surfaces the validated JSON to the lead. The subagent still uses any tools it needs during execution (Grep, Bash, file operations), but the final turn must conform to the structure you defined.

%% alt: Conceptual flow of structured output mode transforming subagent result into synthetic tool call
flowchart TD
    Start("Subagent executes with tools")
    Tools("Uses Grep Bash Read Write")
    Synth("SDK wraps result in synthetic tool")
    Valid("Validates against JSON Schema")
    Lead("Lead receives structured_output")
    Retry("Max retries exceeded")

    Start --> Tools
    Tools --> Synth
    Synth --> Valid
    Valid -->|pass| Lead
    Valid -->|fail| Retry

    style Lead stroke:#34d399,fill:#0b3b2e,color:#d1fae5
    style Retry stroke:#ef4444,fill:#450a0a,color:#fca5a5
Conceptual flow of structured output mode transforming subagent result into synthetic tool call

The schema is a JSON Schema object. Zod schemas convert to JSON Schema with zodToJsonSchema() from the zod-to-json-schema package. The SDK supports standard JSON Schema features: object, array, string, number, boolean, null, enum, const, required, nested objects, and $ref definitions. The format keyword (like "format": "email") is accepted as an annotation but not enforced. Before SDK v2.1.205, invalid schemas were silently ignored and the subagent returned unstructured text. After v2.1.205, an invalid schema fails the run at startup with an error naming the problem.

The agent attempts the synthetic tool call up to the retry limit (default 3). If validation fails on every attempt, the result becomes an error of type error_max_structured_output_retries. Your code sees that error directly on the result message's subtype, so check it before trusting structured_output.

Forcing JSON Responses From Subagents: Passing outputFormat to a query() Session

A worker session accepts outputFormat in the same shape as any other query() call. Define a Zod schema, convert it to JSON Schema, and pass it to query(). The example below spawns a query() session to extract repository metadata and return it as a typed object:

import { z } from "zod";
import { zodToJsonSchema } from "zod-to-json-schema";
import { query } from "@anthropic-ai/claude-agent-sdk";

const repoMetadataSchema = z.object({
  name: z.string().describe("Repository name"),
  primaryLanguage: z.string().describe("Primary programming language"),
  stars: z.number().int().nonnegative().describe("Star count"),
  openIssues: z.number().int().nonnegative().describe("Open issue count"),
  lastCommitDate: z.string().describe("ISO 8601 date of last commit")
});

type RepoMetadata = z.infer<typeof repoMetadataSchema>;

const jsonSchema = zodToJsonSchema(repoMetadataSchema, {
  target: "draft-7"
});

async function analyzeRepository(repoPath: string): Promise<RepoMetadata> {
  const messages = [];

  for await (const message of query({
    prompt: `Analyze the repository at ${repoPath} and extract metadata`,
    options: {
      outputFormat: {
        type: "json_schema",
        schema: jsonSchema
      }
    }
  })) {
    messages.push(message);

    if (message.type === "result" && message.subtype === "success") {
      if (!message.structured_output) {
        throw new Error("Expected structured output but received none");
      }
      return message.structured_output as RepoMetadata;
    }

    if (message.type === "result" && message.subtype === "error") {
      throw new Error(`Subagent failed: ${message.error}`);
    }
  }

  throw new Error("Subagent completed without result");
}

The subagent uses Bash to run git log, Grep to search for language indicators, and Read to examine configuration files. The final result matches the schema or triggers a retry. The lead receives a typed RepoMetadata object with no parsing layer.

Optional fields follow Zod's .optional() pattern. The JSON Schema includes them in properties but omits them from required. When the subagent cannot populate an optional field (like an author name for a file with no git history), it omits the key from the synthetic tool call, and TypeScript infers the field as string | undefined:

const todoSchema = z.object({
  text: z.string(),
  file: z.string(),
  line: z.number().int().positive(),
  author: z.string().optional(),
  date: z.string().optional()
});

type Todo = z.infer<typeof todoSchema>;

The author and date keys appear in the JSON Schema with no required constraint. The subagent populates them when git blame data exists and omits them otherwise. Downstream code checks todo.author !== undefined before using the value.

Validating Structured Output With Zod: From JSON Schema to Runtime Type Safety

Zod provides both the JSON Schema for the SDK and the runtime validator for the result. The parse() method throws on validation failure. The safeParse() method returns { success: true, data: T } or { success: false, error: ZodError }. Production code typically calls safeParse() right after reading message.structured_output in the result-handling loop, as a second layer of runtime checks (like date-format refinements) on top of the SDK's own schema validation.

The schema from the previous section generates this JSON Schema, which the SDK passes to the model:

{
  "type": "object",
  "properties": {
    "name": {
      "type": "string",
      "description": "Repository name"
    },
    "primaryLanguage": {
      "type": "string",
      "description": "Primary programming language"
    },
    "stars": {
      "type": "integer",
      "minimum": 0,
      "description": "Star count"
    },
    "openIssues": {
      "type": "integer",
      "minimum": 0,
      "description": "Open issue count"
    },
    "lastCommitDate": {
      "type": "string",
      "description": "ISO 8601 date of last commit"
    }
  },
  "required": ["name", "primaryLanguage", "stars", "openIssues", "lastCommitDate"],
  "additionalProperties": false
}

Runtime validation applies the same constraints. Zod checks that stars is a nonnegative integer and lastCommitDate is a string. Custom refinements enforce stricter rules:

const repoMetadataSchema = z.object({
  name: z.string().min(1),
  primaryLanguage: z.string().min(1),
  stars: z.number().int().nonnegative(),
  openIssues: z.number().int().nonnegative(),
  lastCommitDate: z.string().refine(
    (val) => !isNaN(Date.parse(val)),
    { message: "Must be a valid ISO 8601 date" }
  )
});

The refinement on lastCommitDate rejects malformed date strings like "2026-13-01". The SDK's validation catches basic type mismatches, and Zod's refinement catches semantic errors. When a subagent returns "2026-13-01", the synthetic tool call fails validation, the SDK retries, and the subagent eventually corrects itself or exhausts retries.

Zod validation pipeline from JSON Schema to runtime type checking

Zod v4 (released in late 2025) changed the refinement API and the shape of ZodError. The zodToJsonSchema() function supports both Zod v3 and v4. Projects upgrading to Zod v4 must update error-handling code that inspects error.issues directly, because the issues array structure changed. The JSON Schema output remains compatible across versions.

Result-Loop Validation: Checking Output Before Your Application Trusts It

The SDK's own validation only checks the synthetic StructuredOutput tool call against your JSON Schema; it does not run your Zod refinements. Those run in your code, in the for await loop that consumes the result message, right after you read message.structured_output and before anything downstream touches it.

%% alt: Execution flow showing result-loop validation before the caller receives typed data
flowchart LR
    Sub("query() session completes")
    Result("Result message with structured_output")
    Zod("Zod safeParse validation")
    Pass("validation passes")
    Lead("Caller receives typed result")
    Fail("validation fails")
    Retry("Caller handles or retries")

    Sub --> Result
    Result --> Zod
    Zod --> Pass
    Pass --> Lead
    Zod --> Fail
    Fail --> Retry

    style Lead stroke:#34d399,fill:#0b3b2e,color:#d1fae5
    style Zod stroke:#c084fc,fill:#3b0764,color:#f3e8ff,stroke-width:4px
    style Fail stroke:#fbbf24,fill:#3a2f0b,color:#fef3c7
Execution flow showing result-loop validation before the caller receives typed data

The example below validates repository metadata as soon as the result message arrives, and treats a refinement failure as a terminal error for that call rather than a mid-session retry:

import { z } from "zod";
import { zodToJsonSchema } from "zod-to-json-schema";
import { query } from "@anthropic-ai/claude-agent-sdk";

const repoMetadataSchema = z.object({
  name: z.string().min(1),
  primaryLanguage: z.string().min(1),
  stars: z.number().int().nonnegative(),
  openIssues: z.number().int().nonnegative(),
  lastCommitDate: z.string().refine(
    (val) => !isNaN(Date.parse(val)),
    { message: "Must be a valid ISO 8601 date" }
  )
});

type RepoMetadata = z.infer<typeof repoMetadataSchema>;

const jsonSchema = zodToJsonSchema(repoMetadataSchema, {
  target: "draft-7"
});

async function analyzeWithValidation(repoPath: string): Promise<RepoMetadata> {
  for await (const message of query({
    prompt: `Analyze the repository at ${repoPath} and extract metadata`,
    options: {
      outputFormat: {
        type: "json_schema",
        schema: jsonSchema
      }
    }
  })) {
    if (message.type === "result" && message.subtype === "success" && message.structured_output) {
      const result = repoMetadataSchema.safeParse(message.structured_output);

      if (!result.success) {
        const errors = result.error.issues
          .map(issue => `${issue.path.join(".")}: ${issue.message}`)
          .join("; ");

        throw new Error(`Validation failed: ${errors}`);
      }

      return result.data;
    }

    if (message.type === "result" && message.subtype === "error_max_structured_output_retries") {
      throw new Error("SDK could not produce output matching the schema");
    }
  }

  throw new Error("Query completed without result");
}

The SDK's schema validation and retry loop already ran by the time this message reaches your code, so message.structured_output is guaranteed to match your JSON Schema's basic types. The safeParse() call here applies the stricter runtime refinements Zod carries (like the ISO date check) that never reached the SDK, because only the generated JSON Schema was passed to outputFormat.

The pattern scales to multiple workers. A caller spawning ten parallel query() sessions runs the same validation on each result message independently, and only valid results get collected into the caller's own aggregate.

Error Handling: What Happens When Structured Output Validation Fails

The SDK retries failed validation up to the retry limit (default 3). After the limit, the result message's subtype becomes error_max_structured_output_retries. Your result-handling code sees this directly on the message; there is no hook step in between. Production workflows typically branch on subtype right there and log the failure for debugging.

%% alt: Decision tree showing retry loop and eventual failure path for invalid structured output
flowchart TD
    Call("Subagent makes synthetic tool call")
    Valid("SDK validates against schema")
    Pass("Validation passes")
    Lead("Lead receives result")
    Fail("Validation fails")
    Retry("Increment retry count")
    Check("Count < limit?")
    Again("Retry with feedback")
    Error("error_max_structured_output_retries")

    Call --> Valid
    Valid -->|pass| Pass
    Pass --> Lead
    Valid -->|fail| Fail
    Fail --> Retry
    Retry --> Check
    Check -->|yes| Again
    Again --> Call
    Check -->|no| Error

    style Lead stroke:#34d399,fill:#0b3b2e,color:#d1fae5
    style Error stroke:#ef4444,fill:#450a0a,color:#fca5a5
    style Fail stroke:#fbbf24,fill:#3a2f0b,color:#fef3c7
Decision tree showing retry loop and eventual failure path for invalid structured output

The retry loop is automatic. The SDK provides feedback to the model after each failed attempt, describing the validation error and the expected schema. The model corrects its response and tries again. When retries exhaust without a valid result, the error surfaces. The example below catches the error in the main query loop:

async function analyzeWithErrorHandling(repoPath: string): Promise<RepoMetadata | null> {
  try {
    for await (const message of query({
      prompt: `Analyze the repository at ${repoPath} and extract metadata`,
      options: {
        outputFormat: {
          type: "json_schema",
          schema: jsonSchema
        }
      }
    })) {
      if (message.type === "result" && message.subtype === "success" && message.structured_output) {
        const result = repoMetadataSchema.safeParse(message.structured_output);

        if (!result.success) {
          console.error("Validation failed:", result.error.issues);
          return null;
        }

        return result.data;
      }

      if (message.type === "result" && message.subtype === "error_max_structured_output_retries") {
        console.error("SDK retries exhausted without valid output");
        return null;
      }
    }
  } catch (error) {
    console.error("Query threw:", error);
    return null;
  }

  return null;
}

A result can also come back with subtype: "success" but no structured_output at all, for example when the run completes without the agent producing one. Treat that case as a failure too, the same as the explicit retry-exhaustion subtype.

Some validation failures are unrecoverable. When the schema expects an integer and the agent's tools can only return a string, the SDK's own retries will exhaust without progress. Production systems often include a fallback path: if structured output fails, the caller retries with a simpler schema or a prose-based extraction prompt.

Production Patterns: Composing Subagent JSON Schemas for Multi-Agent Workflows

Multi-agent workflows compose schemas hierarchically. A lead spawns a subagent to analyze a repository, and that subagent spawns child subagents to analyze individual files. Each level defines its own schema, and the parent's schema includes the child's schema as a nested object or array.

%% alt: Multi-level workflow showing lead agent receiving composed results from nested subagents
flowchart LR
    Lead("Lead agent defines top-level schema")
    Sub1("Subagent 1 with file analysis schema")
    Sub2("Subagent 2 with file analysis schema")
    Compose("Lead composes results into repository schema")
    Typed("Fully typed repository object")

    Lead --> Sub1
    Lead --> Sub2
    Sub1 --> Compose
    Sub2 --> Compose
    Compose --> Typed

    style Compose stroke:#c084fc,fill:#3b0764,color:#f3e8ff,stroke-width:4px
    style Typed stroke:#34d399,fill:#0b3b2e,color:#d1fae5
Multi-level workflow showing lead agent receiving composed results from nested subagents

The repository metadata schema from earlier examples extends to include an array of file analyses:

const fileAnalysisSchema = z.object({
  path: z.string(),
  language: z.string(),
  lines: z.number().int().positive(),
  complexity: z.number().int().nonnegative(),
  lastModified: z.string()
});

const repoAnalysisSchema = z.object({
  name: z.string().min(1),
  primaryLanguage: z.string().min(1),
  stars: z.number().int().nonnegative(),
  openIssues: z.number().int().nonnegative(),
  lastCommitDate: z.string(),
  files: z.array(fileAnalysisSchema)
});

type RepoAnalysis = z.infer<typeof repoAnalysisSchema>;

The lead spawns a subagent with outputFormat set to the repoAnalysisSchema. That subagent spawns child subagents to analyze individual files, each with outputFormat set to fileAnalysisSchema. The lead receives a single RepoAnalysis object with fully typed nested data. Validation at each level guarantees that every file analysis conforms to fileAnalysisSchema and the repository analysis conforms to repoAnalysisSchema.

The composition pattern scales to arbitrary nesting depth. A subagent analyzing a file might spawn subagents to analyze functions, and those subagents return function-level schemas. The top-level lead receives a deeply nested typed object with no manual assembly.

Parallel subagents often return arrays. A lead spawning ten subagents to analyze ten repositories defines a schema like this:

const batchAnalysisSchema = z.object({
  repositories: z.array(repoAnalysisSchema),
  totalStars: z.number().int().nonnegative(),
  mostActiveRepo: z.string()
});

The lead spawns ten child subagents, each returning a RepoAnalysis object. The lead collects the results, computes totalStars and mostActiveRepo, and returns a batchAnalysisSchema-shaped object. The parent that spawned the lead receives a single typed payload summarizing ten repositories.

Comparison of schema composition strategies:

StrategyUse caseValidation overheadType safety
Flat schemaSingle subagent, simple outputLow (one validation)Full (single-level inference)
Nested schemaHierarchical analysis (repo → files)Medium (validation per level)Full (deep inference with nested types)
Array schemaParallel subagents returning same shapeHigh (validation per element)Full (array element type inferred)
Discriminated unionSubagents returning different shapesMedium (one validation, branching types)Full (union type inferred)

Discriminated unions handle cases where subagents return different shapes based on runtime conditions. A subagent analyzing a file might return different schemas for source files versus configuration files:

const sourceFileSchema = z.object({
  type: z.literal("source"),
  path: z.string(),
  language: z.string(),
  functions: z.array(z.string())
});

const configFileSchema = z.object({
  type: z.literal("config"),
  path: z.string(),
  format: z.string(),
  keys: z.array(z.string())
});

const fileSchema = z.discriminatedUnion("type", [
  sourceFileSchema,
  configFileSchema
]);

type FileAnalysis = z.infer<typeof fileSchema>;

The subagent returns a type field that determines the shape. TypeScript narrows the type based on the discriminant:

function processFile(file: FileAnalysis) {
  if (file.type === "source") {
    console.log(`Functions: ${file.functions.join(", ")}`);
  } else {
    console.log(`Config keys: ${file.keys.join(", ")}`);
  }
}

This pattern is common in workflows where a subagent inspects a file and decides the appropriate analysis strategy at runtime. The lead receives a single schema that accommodates both outcomes, and TypeScript enforces exhaustive handling of the union.

Frequently Asked Questions

What happens if a query() session exhausts retries without producing valid structured output?

The SDK yields a result message with type: "result" and subtype: "error_max_structured_output_retries". Your result-handling code reads this subtype directly off the message and can branch into a fallback strategy right there; there is no hook in between.

Can structured output mode work with custom tools defined in the agent session?

Structured output mode wraps the final result in a synthetic tool call, separate from any custom tools the agent uses during execution. The agent can call custom tools (like a database query tool) as many times as needed, then return the final result via the synthetic tool. Custom tools do not need to match the output schema; only the final result does.

How do I migrate from regex parsing to structured output mode in an existing workflow?

Replace the prose prompt (like "return the data as JSON") with an outputFormat option. Define a Zod schema matching the shape your regex currently extracts, convert it to JSON Schema with zodToJsonSchema(), and pass it to query(). Remove the regex parsing code and read message.structured_output directly. Add a safeParse() check in your result-handling loop to catch any edge cases your regex missed before trusting the output.

Does structured output mode increase latency compared to unstructured responses?

Structured output mode adds one synthetic tool call at the end of the session's execution. Latency increases by the time to generate and validate that call. Retries on validation failure add incremental latency, but the retry loop is automatic and parallel across multiple sessions, so ten parallel workers with retries often complete faster than sequential prose parsing.

Can I use Zod v4 refinements with the Claude Code SDK?

Zod v4 refinements work with the SDK because zodToJsonSchema() supports both Zod v3 and v4. The refinement runs at runtime in your own result-handling code, not inside the SDK's validation. The SDK validates basic types against the JSON Schema, and Zod's safeParse() applies refinements like date format checks or custom business logic.

Conclusion: Building Reliable Agent Pipelines With Structured Output and Zod

Structured output mode in Claude Code eliminates regex parsing from multi-agent workflows. Agent sessions return validated JSON matching schemas you define, and Zod enforces type safety from the schema definition through runtime validation. Your result-handling loop reads message.structured_output off the result message and applies Zod's runtime refinements before anything downstream touches it, so invalid payloads never propagate silently. Production pipelines compose schemas hierarchically, spawning worker sessions that return typed objects fitting directly into the parent's schema. Related patterns for cost control and CI integration appear in Claude Code cost control for production workflows and CI agentic review with auto-fix. Compare the 2026 tooling landscape in Claude Code versus Cursor and Windsurf.
